JIO-1023-DX 2MP 10X Optica Zoom Starlight Camera Module integrates an 10X optical electric zoom movement and a 2-megapixel high frame rate ultra starlight CMOS sensor, supporting electronic image stabilization, electronic fog transmission, distortion correction, shadow correction, corridor mode, etc., to adapt to all-weather monitoring environments.
● Starlight level
● 10x optical zoom, 32x digital zoom
● 30Pin Lvds connector, Pin to Pin Sony connector;
● 1080p/720p (50/25fps, 60fps/30fps)
● 4.7mm-47mm
● Digital Noise Reduction (2 D+ 3D)
● Privacy mask function
● Strong light suppression
● Motion Detection
● Fog Transparency
● Support VISCA, PeIco-D/P protocols
● Video Output: LVDS, CVBS
| model | JIO-1023-DX |
| Movement parameters | |
| Sensor type | 1/2.8" Panasonic CMOS |
| Effective pixel | Two million |
| minimal illumination | Color: 0.02 Lux; black and white: 0.001 Lux |
| noise-signal ratio | ＞50dB |
| Day and night switching mode | Automatic ICR filter switch, automatic, color, black and white |
| Lens parameters | |
| focal distance | And f =4.7 – 47mm, 10 x optical changes and 32 x numbers |
| iris diaphragm | Maximum aperture: F 1.7 to F 3.1 |
| shutter | 1 / 1 seconds to 1 / 30,000 seconds; slow shutter support |
| Horizontal field of view angle | 58.3-7.1 degree (wide Angle-looking far) |
| image parameter | |
| resolution ratio |
50/25fps (1920 × 1080,1280 × 720); 60/30fps (1920 × 1080,1280 × 720)； |
| Focus mode | Automatic focus / manual focus / one-click automatic focus |
| Strong light inhibition | support |
| Privacy block | Support 8 regions |
| Mobile detection | Support 4 regions |
| 3D & 2D for noise reduction | support |
| Through the fog | support |
| Baud rate | 2400 / 4800 / 9600 / 19200 / 38400 / 57600 / 115200 |
| access protocol | VISCA / PeIco-D / PelcoP / Update |
| language | English / simplified Chinese / Traditional Chinese / Japanese |
| standard | NTSC / PAL |
| interface parameters | |
| video monitor 525 vidicon video out | LVDS , CVBS |
| general requirements | |
| Operating temperature and humidity | -10℃ ~50℃, humidity is less than 90% (no condensation) |
| power suppl | DC 9V -15V |
| size | 66*43.6*47mm |
| weight | 165g |
If there is any change in product design and specifications, real-time update cannot be guaranteed. Specification parameters and pictures are for reference only, and the details are subject to the physical object.
For more information on our products, please contact Jioptik.
