● With the function of setting the irradiation period, and can be laser irradiation according to the set period.
● 45mJ Laser Target Designator and Rangefinder has the function of setting and storing pseudorandom code sequence, and can be irradiated according to the set code sequence.
● With laser single and repeated ranging functions.
● With multi-target ranging function.
● It has the temperature output function of the core parts of the device.
● It has the function of protecting the rangefinder & irradiator from overheating.
● It has the function of status information output of rangefinder & irradiator.
You are welcomed to come to our factory to buy the latest selling, low price, and high-quality 45mJ Laser Target Designator and Rangefinder. We look forward to cooperating with you.
1.Wide temperature non-thermal system design, strong anti-tuning ability, good optical axis stability, can achieve a wide temperature range of work;
2.Using unique pulse detection and automatic compensation technology, high energy stability;
3.Choose active Q-switching pump mode, fine adjustment step, high coding precision.
| Model | STA-LD6445M | ||
| Item | Unit | Parameter | Remarks |
| Wavelength | nm | 1060±5 | |
| Laser average energy | mJ | ≥45 | |
| Energy stability (RMS) | % | ≤8 | |
| Laser beam divergence Angle | mrad | ≤0.3 | |
| Laser emission axis stability | mrad | ≤0.05 | |
| The laser emission axis no parallelism to the mounting base plane | ≤3′ | ||
| Laser pulse width | ns | 10-22 | |
| Illumination distance | Km | ≥3km (ground); | 5km (air-to-ground); |
| Ranging capability | Km | 8km | Visibility 15km, ranging distance for large targets |
| Km |
Maximum: ≥4km Minimum: ≤200m |
Under the condition that the visibility is not less than 10km, the low small and slow UAV (equivalent size 0.2m×0.2m) | |
| Range repetition rate | Hz | 5 | |
| Range accuracy (RMS) | m | ≤ ±2 | |
| Range rate | % | ≥ 98 | |
| Laser coding CT | ms | 40 ~ 100 | Set by communication protocol |
| Laser coding timing accuracy | μs | ≤ ±1 | |
| Operating temperature | °C | -40 ~ +60 | |
| Storage temperature | °C | -55 ~ +70 | |
